SR 5015

124900

  • 8K Reciever
  • 7 x 180 Watts (6 ohms, 1%)
  • 8K/60Hz and 4K/120Hz Pass-Through
  • eARC. HDMI Support • HEOS Built-in
  • Supports all your favourite voice assistants
SKU: Marantz_SR 5015

Description

Enjoy exquisite video performance thanks to the latest HDMI technologies such as 8K/60Hz pass-through and upscaling, various HDR format support including HDR10, HDR10+, Dolby Vision, Hybrid Log-Gamma (HLG) and Dynamic HDR. Game with better immersion thanks to 4K/120Hz pass-through, Variable Refresh Rate (VRR) and Auto Low Latency Mode (ALLM).

Extensively tuned by world-renowned sound acousticians at the most state-of-the-art facilities, the new Marantz SR5015 leverages decades of experience in Hi-Fi to drive exceptional, audiophile-quality surround sound for all your entertainment.

Key Features

  • Performance, power and connectivity to suit your audio preferences:7.2 channel discrete power amplifier, 100W per channel (8 Ohm, 20Hz-20kHz, THD: 0.08%, 2ch. drive).
  • 8K/60Hz and 4K/120Hz pass-through support for every entertainment need:With the latest technology in HDMI support, enjoy 8K quality video from your 8K source devices. 8K upscaling is available on all 6 HDMI ports.
  • Support for the most advanced object-based audio formats:Dolby Atmos®, Dolby Atmos Height Virtualization Technology, DTS:X® and DTS Virtual:X™ processing are all supported to allow you to listen to immersive, multi-dimensional audio.
  • Enhanced Audio Return Channel (eARC) HDMI support:Through the main HDMI output, connect your TV with eARC HDMI support to allow uncompressed and object-based audio formats like Dolby Atmos® and DTS:X® directly from a smart TV app to your AV receiver.
  • Bringing you the latest in video compatibility:Support for the latest HDR formats including HDR10, HDR10+ (New in 2020), HLG, Dolby Vision, 4:4:4 color resolution and BT.2020, as well as Dynamic HDR (New in 2020) provides exceptional picture quality for brightness, clarity and contrast.
  • The greatest technology for home cinema:With 8K/60Hz pass-through and upscaling, Dynamic HDR and Quick Media Switching (QMS), enjoy crystal clear picture and accurate detail.
  • Advanced gaming specifications:With 4K/120Hz pass-through, Variable Refresh Rate (VRR), Auto Low Latency Mode (ALLM) and Quick Frame Transport (QFT), experience gaming thrills with amazing imaging and reduced lag.
  • High-resolution streaming for audiophile approved sound:Ability to decode ALAC, FLAC and WAV lossless files up to 24-bit/192-kHz; DSD 2.8MHz and 5.6MHz tracks — enjoy your music exactly as the artist intended.
  • Exclusive components elevate Marantz sonic signature:Marantz proprietary HDAM circuit boards, Current Feedback circuitry, AKM AK4458 32-bit D/A converters, and Hybrid PLL Clock Jitter Reducer produce more detailed, dynamic sound.
  • Stream music from your favorite sources:Play songs from Spotify, Pandora, TIDAL and more via AirPlay 2, Bluetooth, Wi-Fi and HEOS® Built-in.
  • Features HEOS® Built-in:Advanced technology enables multi-room audio, voice control and digital music streaming throughout your entire home.
  • Supports all your favorite voice assistants:With the SR5015, simply use your voice to control your preferred voice assistant like Amazon Alexa, Google Assistant, Apple Siri and Josh.ai.


Additional information

Weight 10.11 kg
Multichannel Surround

DTS Neural:X DTS Virtual:X Dolby TrueHD / Dolby Atmos/Dolby Atmos Height Virtualization Dolby Surround Multichannel Stereo Max Number of Processing (Preamp) Channels – 7.1

Sound Enhancements

Discrete Power Amplifier Power Transformer: EI Current Feedback Topology Hyper Dynamic Amplifier Modules (HDAM) Pure Direct Audyssey – MultEQ XT Audyssey Dynamic EQ / Dynamic Volume Audyssey APP Support Compressed Audio Enhancer: MDAX2

Network

HEOS Multi-room and Streaming Network Audio Sharing Lossy Formats: MP3 / WMA / AAC Lossless formats FLAC / ALAC / WAV Lossless formats: FLAC HD 192/24 / WAV 192/24 / ALAC 192/24 DSD Audio Streaming – (2.8/5.6MHz) FLAC HD 192/24 WAV 192/24 ALAC 192/24 Gapless Playback – (FLAC, WAV ,ALAC ,DSD) AirPlay Audio Streaming – AirPlay2 Internet radio – TuneIn Compatible with Remote APP for Smart Phones Compatible with Remote APP for Tablets Ethernet Ports Wi-Fi Bluetooth

HDMI

HDMI Inputs: Back / Front – 6 / 0 HDMI Outputs: Main / Zone – 2/0 Video Conversion Analog -> HDMI Analog to HDMI Scaling – 480i/576i up to 8K 60/50 HDMI to HDMI Scaling – up to 8K 60/50 GUI Overlay on HDMI Enhanced ARC 3D Signal Pass-Through 4K Signal Pass-Through / Scaling / GUI Overlay HDMI Pass-Through in Standby Mode Picture Adjust / Noise Reduction CEC Audio Return Channel Auto LipSync

Multi-room CI

HEOS Multi-Room Integrated HEOS Link Compatibility: IR/ IP Multi-Room Zones – 2 Zone Audio Source: HDMI / Opt, Coax / Network, USB / Analog Zone Audio Output: Speaker / Preout IP Control / RS232 Control / App Control IR Flasher In Marantz Remote Bus DC Trigger Output – 1 HDMI Diagnostics

Inputs Outputs

Composite In / Out – 2+1 / 1 Component In / Out – 2 / 1 HDMI In / Out – 6 / 2 Analog In / Out – 4+1 / 0 Phono (MM) In Digital In: Optical / Coaxial – 2 / 2 Multi-Room Out: Analog / Digital – 1/0 Multichannel Pre Out – 7.2 Subwoofer Out – 2 Speaker Terminal: Regular Screw Number of Speaker Terminals – 7 Speaker A / B – assignable Bi-Amp Drive – assignable Multi-Room Speaker Terminal – assignable Front Inputs: Audio / Composite / USB USB Audio AM/FM Tuner

Specifications

Number of poweramps – 7 Power Output (8 ohm, 20 Hz – 20 kHz, 0.08% 2ch Drive) – 100 W Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive) – 140 W Power Output (6 ohm, 1 kHz, 10% 1ch Drive) – 200 W 70% Guarantee

Others

Auto Speaker Setup by Microphone – Audyssey MultEQ XT FL Display – port hole Graphic User Interface – GUI – Advanced ISF Certification GUI Languages – 3 Setup Assistant Smart Select Firmware Update by Network / USB Variable Cross Over Optimized Bass Redirection ECO Mode Auto Power off Sleep / Timer

Dimensions

Antenna:Horizontal:(W x D x H) in inches – 17.3 x 13.7 x 6.3 Antenna:Vertical :(W x D x H) in inches – 17.3 x 13.7 x 9.1 W/o Antenna:(W x D x H) in inches – 17.3 x 13.3 x 6.3

General

System Remote Control – RC042SR Power Consumption in W – 650 Power Consumption No-Sound (ECO on/off) in W – 45 W / 75 W Standby Consumption in W – 0.2 CEC Standby Consumption in W – 0.5 Network Standby Consumption in W – 2.7
